Power box, slots
in or clamps onto
desktop
Remove cover (a) and snap
off the central part.
Attach cover (b) and insert
power box (c) into the desk
adapter and tighten the grub
screw (d), (SW3).
Slide power box clamp (e)
onto desk top. Tighten from
beneath with grub screws (f),
(SW4). Slide power box (g)
onto clamp and clip in place.
24.
Power box, clips
onto desktop screen
or fly-by screen
shown)
Insert slot nuts (a) into orga-
niser groove.
Mount adapter plate (b) onto
slot nuts using counter-sunk
screws M6x12, (SW4).
Slide power box (c) onto
adapter plate and clip in
place (d).
snap off
(a)
(not
(a)
(c)
(e)
(f)
(b)
(d)
