4.
INSTALLATION PRINCIPLE/LAB 400 VARIATIONS
4.1 OVERVIEW
For overview drawing, see page 2.
4.2 LabSystem COMPONENTS
EMD 400 BLEED PRESSURE REDUCER
(also EMD 400-01 in analysis design), single-stage with metal membrane. Available electro-polished
in nickel-plated brass or special steel. Input 3/8" internal screw thread or G 1/4" internal screw thread
from the left side, 3 outputs G 1/4" internal screw thread right, above (manometer) and below. Can
be combined with MVA 400 G, MVR 400 W and MVA 400 W.
EN
Marking input: output:
Marking input:
PRELIMINARY SHUT-OFF VALVE MVA 400 G
with metal membrane for bleed points. Available electro-polished in nickel-plated brass or special
steel. Input G 3/8" internal screw thread, output G 3/8" external screw thread. Can be combined with
EMD 400, MVR-A400 and MVA 400 W.
WALL SHUT-OFF VALVE MVA 400 W 00
with metal membrane. Available electro-polished in nickel-plated brass or special steel. Input G
3/8" internal screw thread, output G 3/8" external screw thread. Can be combined with EMD 400,
MVR-A400 und MVA 400 W.
FLAME ARRESTER FS 400
Material: brass (nickel-plated) for C
EMD 400.
VOLUMETER SVM 400
without adapter, with control valve, allows the specific bleeding of different flow volumes. Material:
black anodized aluminium. Input G 1/4" m, output 6 mm tube fitting. Can be combined with EMD
400.
+
Detailed descriptions with advice on ordering can be obtained from the manufacturer.
4.2 INSTALLATION AND FITTING ACCESSORIES*
Rosette, adapter G 3/8"m >** G 3/8"m, standard G 1/4"f > G 3/8"m, wall adapter NPT 1/4"f > G 3/8"m,
seals, reducing adapter G 3/8"f > G 1/4"f, sealing cap, adapter G 1/4"m > G 1/4"m, open-end wrench
SW 36, spacer G 3/8"f > G 3/8"m, angle adapter ZB 400 G 3/8"f > G 1/4"f, flame arrester FS 400 ,
screw joint G 1/4" > tube fitting, hose nozzle connection for EMD 400 G 1/4" > hose nozzle, threaded
reducing connection pipe 6 mm > screwed clamping ring connection, hose nozzle connection for
MVRA400 G 1/4" > hose nozzle, supporting sleeve 6 x 4 mm, manometer RM 50 connection: G 1/4"m,
volumeter SVM 400 without adapter G 1/4"f > G 1/4"f.
*) For detailed descriptions with advice on ordering, see separate specification sheet "Installation
and fitting accessories", available from bei GCE.
**) G 3/8" m > G 3/8"f means: input G 3/8" external screw thread and output G 3/8" internal screw
thread.
output:
H , O , H . Input G 1/4" m, output G 1/4" f. Can be combined with
2 2 2 2
