Recommendations

Improper use and/or incorrect maintenance of products working with
high internal pressures cause malfunctioning and damages to people
and machines.
It is necessary to carefully conform to the simple instructions given
in this handbook replacing, in case, the faulty or worn components by
original Faster spare parts.
MultiFaster system is characterized by having a lever with intergated
cam in order to perform connections even with hydraulic lines under
pressure.
Before using the MultiFaster ensure that its working pressure is
suitable for the application. This check activity has to be carried out
both on the single couplings and on the whole lines.
MultiFaster 2P... series: consider that during the connection phase
a volume reduction occurs in the male coupling, causing a pressure
increase depending also on the oil quantity in the circuit. For this
reason it is necessary to act on the lever higher effort.
MultiFaster 3P... series: thanks to the new 3 series male couplings no
volume reductions occurs, in this way connection effort even under
pressure is comparable to the one without pressure inside.
Carrefully clean both the fixed and the mobile part before each
connection in order to ensure a longer service life to the seals.
Check that all working components are properly cleaned and greased.
Be sure that the safety lock releases once connection is completed.
During the disconnection phase hold the lever in a firm way in order to
prevent any reaction due to the internal working pressure.
Once MultiFaster is disconnected, close the protective dust cap
assembled on the fixed part and place the mobile part onto its specific
support (available on request).
All technical data regarding working preformances of the MultiFaster
are included in the specific catalogue.
Data and drawings within this handbook are for information only and not binding.
