Lever Replacement, Safety Lock Replacement - Faster Multifaster SPEL 08-3 Installation

11
Lever Replacement - Fixed By Screws
Remove the screws 1, 2 and the
clearing washer 4. Remove the
damaged lever. Insert the new
lever. Lubricate the holes 3.
Insert the screws 1 and 2 and
screw them with 12 +2-0 Nm
torque.
Lever Replacement - Fixed By Shaft
Unscrew the nut 1. Remove the
damaged lever. Clean the hole
3 for the shaft 4. Replace the
O-ring 2. Lubricate the O-ring 2
and the shaft D of the new lever.
Insert the new lever.
Screw the nut 1 with a 50±5 Nm.
Safety Lock Replacement
To replace the safety lock according to the model mounted on the plate,
order KIT SP5 or KIT SP6 spare part.
