Faster Multifaster SPEL 08-3 Installation Seite 117

117
3Р5065-5-FMC_РАЗЪЕМ ЕДИНЫЙ ПОДВИЖНЫЙ
Couplings positions.
Pos. Q.ty
A 3
B 1
C 1
D 3
E 1
F 1
G 1
C
D
Kit code Faster
KIT3FNP14GAS MS
T.B.D
KIT3FNP38-12GM
KIT VGP4
SK MF 38
SK MF 14
T.B.D
A
F
B
E
G
C B
Kit components
1/4" male coupling
3/8" male coupling
3/8" male coupling
Pins, seal, nuts, screws, rollers
Mobile plate without couplings
D
A
Seals
Seals
