TCS-Compact
2
4
Cleaning unit
1
Collecting tray
2
Technical Data - Version with short support
Fig. 2
Ambient temperature
Transport and storage
Relative humidity
Tab. 2
Weight
Dimension
Tab. 3
1
370
260
ø 11 (4x)
60
110
Bottle holder for anti-spatter bottle
3
Ambient conditions
Version with long support
approx. 30 kg
approx. 255 mm x 337 mm x 1052 mm
Weight, dimensions
2 Product description
136
2
3
190
Support stand with flange plate
4
+ 5 °C to + 50 °C
- 10 °C to + 55 °C
up to 90 % at 20 °C
Version with short support
approx. 22,3 kg
approx. 255 mm x 337 mm x 477 mm
EN - 5
