7. OPERATION

Switch on the controller with the rear power
switch. The unit is in manual mode and the
display indicates "Manual" in the upper line. After
switching on, the unit can always call the last
illumination scene if the autostart function is
activated p. 38.
Manual Adjustment of an Illumination
Scene
An illumination scene contains the values of all
control channels including the pan and tilt settings
of the connected light effect units.
1
Use the buttons SCANNER 1-12 to select
the units to be controlled. The corresponding
LEDs of the buttons light. If a button is
pressed once again, the corresponding
device is deselected.
2
Adjust the desired DMX values (0-255) for
the DMX channels using the sliding
controls and, if necessary, the pan and tilt
wheels. As soon as a fader is moved, the
display indicates the current output value as
a DMX value in the upper line. The number
of the control channel and the memory bank
are indicated in the lower line.
3
The button TAP/DISPLAY allows switching
the display indication between per cent value
and decimal value.
4
The 20 control channels are combined in 2
groups (channel pages) of 10 channels each.
If necessary, use the button PAGE SELECT
to switch between the two channel groups 1-
10 (red LED lights) and 11-20 (green LED
lights) and repeat steps 1 and 2, until the
desired values are assigned to all channels.

Memorizing Illumination Scenes

30 memory banks are available for 8 illumination
scenes each. Each scene contains the values of
all control channels including the pan and tilt
settings of the connected light effect units at the
time of storage.
1
Call the programming mode. For this, keep
the PROGRAM pressed until the LED next to
the button flashes.
2
Use the buttons SCANNER 1-12 to select
the units to be controlled. The corresponding
LEDs of the buttons light. If a button is
pressed once again, the corresponding
device is deselected.
3
Adjust the desired DMX values (0-255) for
the DMX channels using the sliding
controls and, if necessary, the pan and tilt
wheels. As soon as a fader is moved, the
display indicates the current output value as
a DMX value in the upper line. The number
of the control channel and the memory bank
are indicated in the lower line.
4
If necessary, use the button PAGE SELECT
to switch between the two channel groups 1-
10 (red LED lights) and 11-20 (green LED
lights) and repeat step 3, until the desired
values are assigned to all channels.
5
Deselect the adjusted devices with the
corresponding button SCANNER 1-12.
6
Repeat the steps 2 to 4 for all further devices
to be adjusted.
7
Press the button MIDI/REC.
8
Use the buttons BANK UP and BANK
DOWN to select the desired memory bank
(1-30).
9
Use one of the buttons SCENE 1-8 to select
the desired memory location. The scene is
memorized. To confirm the memory
procedure, all LEDs of the controller flash
three times.
10
Repeat the steps 2 to 9 to memorize further
scenes.
11
After all desired scenes have been
memorized, switch off the programming
mode. For this, keep the button PROGRAM
pressed until the LED next to the button
extinguishes.

Editing Illumination Scenes

1
Call the programming mode. For this, keep
the PROGRAM pressed until the LED next to
the button flashes.
2
Use the buttons BANK UP and BANK
DOWN to select the memory bank (1-30)
where the desired scene is stored.
3
Load the scene to be edited with the
corresponding button SCENE 1-8.
4
Change the DMX values with sliding
controls and, if necessary, the pan and tilt
wheels.
5
If necessary, use the button PAGE SELECT
to switch between the two channel groups 1-
10 (red LED lights) and 11-20 (green LED
lights) and repeat step 3, until the desired
values are assigned to all channels.
6
Press the button MIDI/REC to memorize the
revised scene.
