Fog Machine

The controller can activate the fog output of a fog machine at the push of a button. Connect the fog machine
to the 5-pin DIN jack.
Occupation of the DIN connection:

MIDI Control

For MIDI control connect the MIDI controller to the 5-pin DIN input MIDI IN.

Connection to the Mains

Connect the power supply unit to the power input jack and the mains plug to a mains outlet. Always
disconnect the mains connector when you wish to change connections, move the unit to a different place or
if it is not used for a longer period.
