Tilt wheel
A-Y
11 Fader 1
Fader 2
12
Fader 3
13
Fader 4
14
Fader 5
15
Fader 6
16
Fader 7
17
Fader 8
18
Pan wheel
B-X
Tilt wheel
B-Y
Table 6.2 Manual assignment of DMX channels to the
control elements
5
Press the button MIDI/REC to memorize
your setting. To confirm the memory
procedure, all LEDs of the controller flash
three times.
6
Repeat the steps 3 to 5 to assign further
DMX channels.
7
Press the button AUTO/DEL to delete an
assignment. To confirm the deleting
procedure, all LEDs of the controller flash
three times and the DMX channel indication
in the lower line changes to "DMXCH:NL"
(Zero).
8
After your settings, switch off the assignment
mode. For this, press the two buttons PRGM
and PAGE SELECT simultaneously.

Inverting Output Values

It is possible to individually invert the output
values of the 240 control channels.
1
Call the assignment mode. For this, press
the two buttons PRGM and PAGE SELECT
simultaneously. The display indicates
"SELECT SCANNER".
2
Use the buttons SCANNER 1-12 to select
the unit of which the DMX channels are to be
inverted (control LED lights).
3
Press the button TAP/DISPLAY to call the
configuration menu for the unit. The LED
ASSIGN lights. The display indicates the
control element in the upper line, e.g.
"FADE:1" and the DMX channel in the lower
line, e.g. "DMXCH:01".
4
Press the button MODE to call the inversion
option. The LED REVERSE lights and the
indication in the lower line changes from
DMX channel to "REV: NO".
5
Adjust the first control element with the pan
wheel and use the tilt wheel to select the
A
B
B
B
B
6
B
B
B
7
B
B
B 8
9
Deleting all DMX Address
Assignments and Control Channel
Options
If necessary, it is possible to delete all DMX
address assignments and control channel options
made and reset them to the default settings.
1
2

Assigning the Fade Function

The fade function can be assigned to all control
channels or only to the pan and tilt wheels. This is
particularly useful e.g. when the mirror or moving
head movement should be carried out slowly,
however, the gobos and colors are to change
quickly.
1
2
3
4
31/40
setting [YES] if the output value of the control
channel is to be inverted or [NO] if not. With
activated inversion the output value is zero if
the control channel has been set to the
maximum value and vice versa.
Press the button MIDI/REC to memorize
your setting. To confirm the memory
procedure, all LEDs of the controller flash
three times.
Repeat the steps 5 and 6 to invert further
control channels.
Repeat the steps 2, 5 and 6 to adjust further
units.
After your settings, switch off the assignment
mode. For this, press the two buttons PRGM
and PAGE SELECT simultaneously.
Keep the two buttons MODE and AUTO/DEL
pressed simultaneously and switch off the
controller. After 2 seconds, all LEDs of the
controller shortly light up.
Turn on the controller. The deleting
procedure is complete and the control
channels can be reconfigured.
Switch off the controller.
Keep the two buttons MODE and
TAP/DISPLAY pressed simultaneously and
switch on the controller.
Use the button TAP/DISPLAY to select the
setting [ALL CH FD TIME] if the fade
function is possible for all control channels or
select [ONLY X/Y FD TIME] if it is only
possible for the pan and tilt wheels.
Keep the two buttons MODE and
TAP/DISPLAY pressed simultaneously to
memorize your setting. To confirm the
memory procedure, all LEDs of the controller
flash three times.
00081310.DOCX, Version 1.0
