Programming and Memorizing Chases

The scenes previously memorized can be
compiled to a chase (scene sequence) in any
desired order and memorized. 6 memory banks
are available. A sequence of up to 240 steps can
be programmed on each memory bank. Chases
may run manually, sound-controlled or time-
controlled.
1
Call the programming mode. For this, keep
the PROGRAM pressed until the LED next to
the button flashes.
2
Select the desired memory bank with one of
the buttons CHASE 1-6.
3
Call the first scene with the buttons SCENE
1-12 (if necessary, select a memory bank
with the buttons BANK UP and BANK
DOWN in advance).
4
Press the button MIDI/REC to memorize the
scene. To confirm the memory procedure, all
LEDs of the controller flash three times.
5
Repeat the steps 3 and 5 to memorize
further scenes. Up to 240 scenes can be
compiled to a chase.
6
After the desired chase has been
memorized, switch off the programming
mode. For this, keep the button PROGRAM
pressed until the LED next to the button
extinguishes.

Inserting a Scene into a Chase

It is possible to insert scenes after the current
editing position.
1
Call the programming mode. For this, keep
the PROGRAM pressed until the LED next to
the button flashes.
2
Select the chase to be extended with one of
the buttons CHASE 1-6.
3
Press the button TAP/DISPLAY. The display
indicates the current editing position, i.e. the
step "STEP 004".
4
Use the buttons BANK UP and BANK
DOWN to select the step after which a new
step is to be inserted.
5
Press the button MIDI/REC.
6
Press the button TAP/DISPLAY.
7
Now, a scene can be inserted after the
current editing position. For this, first call the
memory bank of the scene with the buttons
BANK UP and BANK DOWN; then select
the scene to be inserted with the
corresponding SCENE button.
8
Press the button MIDI/REC to memorize the
revised chase. To confirm the memory
procedure, all LEDs of the controller flash
three times.
9
After the chase has been memorized, switch
off the programming mode. For this, keep the
button PROGRAM pressed until the LED
next to the button extinguishes.

Inserting a Memory Bank into a Chase

It is possible to insert a complete memory bank
(consisting of 8 scenes) into a chase after the
current editing position.
1
Call the programming mode. For this, keep
the PROGRAM pressed until the LED next to
the button flashes.
2
Select the chase to be edited with one of the
buttons CHASE 1-6.
3
Use the buttons BANK UP and BANK
DOWN to select the memory bank (1-30) to
be inserted.
4
Press the button MUSIC BANK COPY.
5
Press the button MIDI/REC to memorize the
revised chase. To confirm the memory
procedure, all LEDs of the controller flash
three times.
6
After the chase has been memorized, switch
off the programming mode. For this, keep the
button PROGRAM pressed until the LED
next to the button extinguishes.

Deleting a Scene from a Chase

It is possible to delete a scene from a chase at the
current editing position.
1
Call the programming mode. For this, keep
the PROGRAM pressed until the LED next to
the button flashes.
2
Select the chase to be edited with one of the
buttons CHASE 1-6.
3
Press the button TAP/DISPLAY. The display
indicates the current editing position, i.e. the
step "STEP 004".
4
Use the buttons BANK UP and BANK
DOWN to select the step to be deleted.
5
Press the button AUTO/DEL to delete. To
confirm the deleting procedure, all LEDs of
the controller flash three times.
6
After the desired scene has been deleted,
switch off the programming mode. For this,
keep the button PROGRAM pressed until the
LED next to the button extinguishes.
