6. CONFIGURATION
Adjusting the DMX Starting Addresses
of the Light Effect Units
Adjust the DMX starting address of the connected
light effect units according to the following
scheme. If identical units are to be controlled
synchronously, they can receive the same starting
address; otherwise each unit must receive an
individual address. For further information, please
refer to the unit's documentation.
Unit
Button
1
SCANNER 1
2
SCANNER 2
3
SCANNER 3
4
SCANNER 4
5
SCANNER 5
6
SCANNER 6
7
SCANNER 7
8
SCANNER 8
9
SCANNER 9
10
SCANNER 10
11
SCANNER 11
12
SCANNER 12
Table 6.1 Default values for the starting address of the
light effect units
Manual Assignment of DMX Starting
Addresses
It is possible to individually assign the DMX
starting addresses to the controller.
1
Switch on the controller with the rear power
switch. The unit is in manual mode and the
display indicates "Manual" in the upper line.
2
Call the assignment mode. For this, press
the two buttons PRGM and PAGE SELECT
simultaneously. The display indicates
"SELECT SCANNER".
Channel
Starting
group
address
A
001
B
011
A
021
B
031
A
041
B
051
A
061
B
071
A
081
B
091
A
101
B
111
A
121
B
131
A
141
B
151
A
161
B
171
A
181
B
191
A
201
B
211
A
221
B
231
3
Use the buttons SCANNER 1-12 to select
the unit of which the DMX starting address is
to be assigned (control LED lights). The
display indicates the DMX starting address of
the unit, e.g. "StartAdr 001".
4
Change the address with the pan wheel. For
addresses that were already assigned, the
display inserts a "!".
5
Press the button MIDI/REC to memorize
your setting. To confirm the memory
procedure, all LEDs of the controller flash
three times.
6
Repeat the steps 2 to 6 to assign further
units.
7
After your settings, switch off the assignment
mode. For this, press the two buttons PRGM
and PAGE SELECT simultaneously.
Manual Assignment of DMX Channels
It is possible to individually assign the DMX
channels of the connected light effect units to the
control elements of the controller (softpatch).
1
Call the assignment mode. For this, press
the two buttons PRGM and PAGE SELECT
simultaneously. The display indicates
"SELECT SCANNER".
2
Use the buttons SCANNER 1-12 to select
the unit of which the DMX channels are to be
assigned (control LED lights).
3
Press the button TAP/DISPLAY to call the
configuration menu for the unit. The LED
ASSIGN lights. The display indicates the
control element in the upper line, e.g.
"FADE:1" and the DMX channel in the lower
line, e.g. "DMXCH:01".
4
Adjust the first control element with the pan
wheel and assign the DMX channel with the
tilt wheel.
Indication
Control
element
1
2
3
4
5
6
7
8
Pan wheel
A-X
30/40
Channel
group
Fader 1
A
Fader 2
A
Fader 3
A
Fader 4
A
Fader 5
A
Fader 6
A
Fader 7
A
Fader 8
A
A
