Only use a stereo shielded cable and 3-pin XLR-plugs and connectors in order to connect the controller with
the fixture or one fixture with another.
Building a serial DMX-chain:
Connect the DMX-output of the DMX Operator with the DMX-input of the nearest projector. Always connect
one output with the input of the next fixture until all fixtures are connected.
Caution: At the last fixture, the DMX-cable has to be terminated with a terminator. Solder a 120
between Signal (–) and Signal (+) into a 3-pin XLR-plug and plug it in the DMX-output of the last fixture.
Projector addressing
Please note that the DMX Operator assigns the DMX-starting addresses every 16 steps. You have to
address every projector to the respective starting address. Otherwise, the channel assignment will not be
correct. All projectors with the same starting address work synchronically.
Projector Starting address
Projector 1 1
Projector 2 17
Projector 7 97
Projector 10 145

6. OPERATION

After you connected the device to the mains, the DMX Operator is ready for use.

6.1 Manual-mode

6.1.1 Call up projectors manually
In the Manual-mode (Program-LED off), you can call up the connected projectors manually and control them
via the channel faders. Please note that the adjusted settings cannot me memorized.
Select the desired projector via the respective projector select button.
Adust the desired function via the channel faders.
Page Select-button:
Via the Page Select-button, you can adjust the channel faders from CH 1-8 to CH 9-16.
Display-button:
Via the Display-button, you can switch the display of the faderway from DMX-value (0-255) to procent (0-
100).

6.2 Programming

A program is a sequence of different scenes that will be called up one after another. With the DMX Operator,
you can program up to 30 different programs (banks) with up to 8 scenes each.
6.2.1 Programming a program
Press and hold the Program-button until the Program-LED flashes in the display. Select the desired program
(bank) via the Bank-buttons.
Select the desired projector via the projector select buttons. Adjust the desired settings via the respective
channel faders. Select the next projector via the projector select buttons and adjust the settings. Press the
Add-button and then the respective Scene-button in order to save the first step. Program the next steps until
the program is finished or the maximum number of steps - 8 - has been reached. Press the Program-button
in order to save the program. The controller is now in the blackout-mode (Blackout-LED illuminated).

6.2.2 Running a program

Press the Bank-buttons and select the desired program. Press the Auto-button and the Auto Trigger LED is
illuminated in the display. Adjust the program speed via the Speed-Fader and the repitition rate via the Fade
Time-Fader.
As an alternative, you can adjust the program speed by tapping the Tapsynch-button twice. The time interval
between the two taps corresponds to the program speed (up to 10 minutes).
Projector Starting address
Projector 3 33
Projector 4 49
Projector 8 113
Projector 11 161
17/36
Projector Starting address
Projector 5 65
Projector 6 81
Projector 9 129
Projector 12 177
