CONNECTIONS

Mains input

Connect the 3-core lead (3 x 1.5 mm²) to the mains supply.
Plug the power-plug into your safety socket.
Brown
Blue
Green/Yellow
The STROBE CONTROLLER ST-1 must be earthed.

Output

Use the Mono Jack (1/4") for connecting your strobe(s) (up to 5 units). Use a one-cord lead with screen (1 x
0,22) as connection cable.
The output signal is analogue 0V = no flash, +10V = one flash.
This controller can control all analogue strobes.

OPERATION

Power: to switch the unit on and off.
Speed: to control the flash speed.

CLEANING AND MAINTENANCE

We recommend a frequent cleaning of the device. Please use a soft lint-free and moistened cloth. Never use
alcohol or solvents!
There are no servicable parts inside the device except for the fuse. Maintenance and service operations are
only to be carried out by authorized dealers.

Replacing the fuse

If the fine-wire fuse of the device fuses, only replace the fuse by a fuse of same type and rating.
Before replacing the fuse, unplug mains lead.
Procedure:
Step 1: Unscrew the fuseholder on the rearpanel with a fitting screwdriver from the housing (anti-
clockwise).
Step 2: Remove the old fuse from the fuseholder.
Step 3: Install the new fuse in the fuseholder.
Step 4: Replace the fuseholder in the housing and fix it.
Should you need any spare parts, please use genuine parts.
live
neutral
earth

DANGER TO LIFE!

Disconnect from mains before starting maintenance operation!
