Calling Illumination Scenes

Illumination scenes can be called manually or
played time-controlled and sound-controlled. As a
basic setting, the manual mode is activated. The
LEDs MANUAL, AUTO and MUSIC indicate the
current setting.
There should be no device selected. If one of the
control LEDs of the SCANNER buttons light,
press the corresponding button for deselecting.
Calling scenes manually
1
Make sure that the manual mode is activated
and the LED MANUAL lights. If necessary,
switch to manual mode with the button
AUTO/DEL.
2
Use the buttons BANK UP and BANK
DOWN to select the memory bank (1-30)
where the desired scene is stored.
3
Use one of the buttons SCENE 1-8 to call
the scene. If the button is pressed once
again, the scene is deselected.
Time-controlled play of scenes
In automatic mode, the scenes stored in a
memory bank will be played time-controlled in an
endless loop.
1
Call the automatic mode with the button
AUTO/DEL so that the LED AUTO lights.
2
Use the buttons BANK UP and BANK
DOWN to select the desired memory bank
(1-30).
3
Use the sliding control SPEED to adjust the
running speed, i.e. how long a scene is
shown, between 10 minutes and 0.1
seconds. The display shortly inserts the
setting, i.e. "WT:2M50S".
4
Use the button TAP/DISPLAY for a more
precise input of the running speed. For this,
press the button twice. The time between the
two actuations of the button defines the time
until the next change of scene (max. 10
minutes). The display shortly inserts the
setting, i.e. "TP:5.0S ".
5
Use the sliding control FADE to adjust the
fade time, i.e. the time between the steps,
between 0 and 30 seconds The display
shortly inserts the setting, i.e. "FT:11:5S".
Sound-controlled play of scenes
In sound-control mode, the scenes stored in a
memory bank will be synchronized with music
pulses at the jack AUDIO or, if the jack is not
connected, via the internal microphone.
1
Call the sound-control mode with the button
MUSIC/BANK COPY so that the LED
MUSIC lights.
2
Use the buttons BANK UP and BANK
DOWN to select the desired memory bank
(1-30). The scenes stored in the memory
bank will be called one after the other in sync
with the sound.
3
The sensitivity of the sound control is
adjustable. For this, keep the button
MUSIC/BANK COPY pressed and
simultaneously use the BANK UP and
BANK DOWN to adjust a value between 0-
100 %. The higher the value, the higher the
sensitivity.
4
Use the sliding control FADE to adjust the
fade time, i.e. the time between the steps,
between 0 and 30 seconds The display
shortly inserts the setting, i.e. "FT:11:5S".
