en | 22 | DCU 220 | Operation
5.7 Operating in tablet mode
The DCU 220 can be used as a conventional laptop as
well as in tablet mode. In tablet mode, the DCU 220 is
operated using a stylus or your fingertip and virtual key-
board instead of the keyboard and touchpad (mouse).
1. Open the DCU 220 until the screen is nearly perpen-
dicular to the keyboard.
2. Rotate the screen 180° counterclockwise.
!
Do not rotate the screen more than 180°, and do
not rotate it clockwise.
3. Fold the screen downward so that the screen display
points upward and the screen lies securely on top
(note the side guides).
4. Push the latch upward.
5. Engage the clip in the cover.
6. Pushed the latch downward until it locks in place.
|
1 689 989 464 2020-04-01
5.8 Printing
You can connect a printer (such as a PDR 377) via the
USB port of the DCU 220.
i
Refer to the printer manufacturer's information for
details of printer drivers and installation.
i
Information on printing can be found in the online
help for the Bosch applications.
5.9 Camera
i
Operation is described in the user manual.
5.10 Information in the case of any faults
Fault Note
The DCU 220 cannot The capacity of the internal storage bat-
be switched on and tery is insufficient to start the DCU 220.
the display remains Connect the external power supply unit.
blank or flickers. If the DCU 220 cannot be started with
the external power supply unit, contact
customer service
DCU 220 A blue One possible reason may be that the
screen is displayed Bosch Bluetooth USB adapter is plugged
after switching on in, in addition to the enabled internal
(after 5-10 minutes). Bluetooth hardware.
Remedy:
1. Remove the Bluetooth USB adapter.
2. DCU 220 Reboot.
i
Additional instructions regarding troubleshooting
can be found in the user manual sec.8.
i
If the preset Win 10 settings are to be restored,
start the recovery process.
