Vc
in m/ 4 6
min
Drill
bit Ø
in
mm
4,5 283 425
5,0 255 382
5,5 232 347
6,0 212 318
6,5 196 294
7,0 182 273
7,5 170 255
8,0 159 239
8,5 150 225
9,0 142 212
9,5 134 201
10,0 127 191
11,0 116 174
12,0 106 159
13,0 98 147
14,0 91 136
15,0 85 127
16,0 80 119
The correct manual feed Vc in meters per minute depends on the diameter of the drill, the
material to be machined, the speed and the cutting material of the drill.
Determining the cutting speed and the speed
Version 1.0 dated 2019-01-17
8 10 12 15 18
566 708 849 1062 1274
510 637 764 955 1146
463 579 695 869 1042
425 531 637 796 955
392 490 588 735 882
364 455 546 682 819
340 425 510 637 764
318 398 478 597 717
300 375 450 562 674
283 354 425 531 637
268 335 402 503 603
255 318 382 478 573
232 290 347 434 521
212 265 318 398 478
196 245 294 367 441
182 227 273 341 409
170 212 255 318 382
159 199 239 299 358
