INFORMATION
Organise the checks according to the following table;
General check
Equipment
Guards
Signs,
Markers
Date:
Functional check
Equipment

Emergency stop switch

Position switch of protective cover
V-belt
Date:
1.11 Emergency stop switch
CAUTION!
The drilling spindle keeps turning for a short time even after actuating the emergency
stop switch depending on the preset speed.

1.11.1 Drilling table

Seats for T-slots are attached to the clamping table.
WARNING!
Risk of injury due to workpieces flying off at high speed. Securely fix the workpiece on
the drilling table.
1.12

Separating protective devices

1.12.1 Drill chuck guard

Adjust the guard to the correct height before you start working. To do this, loosen the clamping
screw, set the required height and tighten the clamping screws again.

1.12.2 Protective cover of the V-belts

A protective cover for the belt pulleys is mounted on the drilling head. There is a switch inte-
grated in the protective cover which monitors that the cover is closed.
INFORMATION
The machine cannot be started, if the protective cover is not closed.
GB B17Pro basic
Page 42
®
Check
Mounted, firmly bolted and not damaged
Installed and legible
Checked by (signature):
Check
After actuating the emergency-stop switch the bench
drill must be switched off.
The bench drill must not be switched on, if the protec-
tive cover of the V-belts is opened.
Checked by (signature):
Translation of the original instructions
OK
OK
Safety
Version 1.0 2019-01-17
