18

11.2 Setting ranges for the switching outputs

Measurement Lower limit of RP
range (FL)
Level of
saturation
in % in %
0 .. 100 1.0
* All ranges given in the table can be adjusted by the increments shown.
SP = switch point; RP = switch-back point; FL = pressure window lower value; FH = pressure window upper value
Measurement Lower limit of RP
range (FL)
Temperature
-25 .. 100 °C -23.5 °C
-13 .. 212 °F -10 °F
* All ranges given in the table can be adjusted by the increments shown.

11.3 Analogue output

The universal output "ou2" can be set to 4 .. 20 mA or 0 .. 10 V (corresponding to measuring
range) and can be assigned to saturation level or to temperature.
NOTICE:
If the sensor is operated in conjunction with an IO-Link master and if pin 2
is used as an analogue output, pin 2 may not be connected with the IO-Link
master, as it does not support analogue signals.
Edition: 2020-04-20
Upper limit of
SP (FH)
in %
100.0
Upper limit of
SP (FH)
100 °C
212 °F
HYDAC ELECTRONIC GMBH
AS 3000 IO-Link
Min. difference Increment*
betw. RP and
SP & FL and FH
in % in %
1.0 0.2
Min. difference Increment*
betw. RP and
SP & FL and FH
1.5 °C 0.5 °C
3 °F 1 °F
Part No.: 670006 E
