HYDAC ELECTRONIC AquaSensor AS 3000 Bedienungsanleitung Seite 36

36
Variable "SP States" index=72 id=V_SpStates
data type: 8-bit Record (subindex access not supported)
access rights: ro
dynamic
bit
subindex
offset
1 0
2 1
3 2
4 3
Octet 0
bit offset 7
subindex / / / / / /
Variable "Q1 Mapping" index=73 id=V_Q1Mapping
data type: 8-bit UInteger
allowed values: 0 = Primary Value SP1 (BDC1), 1 = Secondary Value SP1 (BDC3)
default value: 0
access rights: rw
octet 0
bit offset 7 - 0
element bit 7 - 0
Variable "Q2/QA Mapping" index=74 id=V_Q2QAMapping
data type: 24-bit Record (subindex access not supported)
access rights: rw
bit
subindex
offset
1 16 8-bit UInteger
2 8 8-bit UInteger
3 0 8-bit UInteger
octet 0
bit offset 23 - 16
subindex 1
element bit 7 - 0
Stand: 20.04.2020
allowed
data type default value
values
Boolean
Boolean
Boolean
Boolean
6 5 4
/ / / / / / / / / / / / / / / / / /
allowed
data type
values
0 = Primary
Value SP2
(BDC2), 1 =
Secondary
Value SP2
(BDC4)
0 = digital
(Q2), 1 =
analog (QA)
0 = 4..20mA,
1 = 0..10V
1 2
15 - 8 7 - 0
2 3
7 - 0 7 - 0
HYDAC ELECTRONIC GMBH
mod.
other var.
false Primary Value SP1
false Primary Value SP2
false Secondary Value SP1
false Secondary Value SP2
3 2
4 3
default mod.
value other var.
0
0
0
AS 3000 IO-Link
name description
1 0
2 1
name description
Output Source
Output Mode
Analog Mode
Mat. Nr.: 670006
