AS 3000 IO-Link
Variable "Display Mapping" index=75 id=V_DspMapping
data type: 8-bit UInteger
allowed values: 0 = Primary Value, 1 = Secondary Value
default value: 0
access rights: rw
octet 0
bit offset 7 - 0
element bit 7 - 0
Variable "Primary Value Display Unit" index=76 id=V_PrimaryValueDspUnit
data type: 8-bit UInteger
allowed values: 0 = %
default value: 0
access rights: rw
octet 0
bit offset 7 - 0
element bit 7 - 0
Variable "Secondary Value Display Unit" index=77 id=V_SecondaryValueDspUnit
data type: 8-bit UInteger
allowed values: 0 = C, 1 = F
default value: 0
access rights: rw
octet 0
bit offset 7 - 0
element bit 7 - 0
Variable "Primary Value Range" index=80 id=V_PrimaryValueRange
data type: 72-bit Record (subindex access not supported)
access rights: ro
bit
subindex
offset
1 56 16-bit Integer
2 40 16-bit Integer
3 32 8-bit Integer
4-octet String
4 0
octet 0
bit offset 71 - 64
subindex 1
element bit 15 - 8
octet 8
bit offset 7 - 0
subindex 4
Stand: 20.04.2020
allowed
data type
values
See 11.2
See 11.2
UTF-8
1 2
63 - 56 55 - 48 47 - 40
1 2
7 - 0 15 - 8 7 - 0
HYDAC ELECTRONIC GMBH
default mod.
value other var.
0
1000
1
"PErC"
3 4 5
39 - 32 31 - 24
2 3 4
7 - 0
37
name description
Lower Value
Upper Value
Decimals
Unit
6 7
23 - 16 15 - 8
4 4
