1. Put the cable from the retrofit kit into the spindle half pipes.
Thread cable within spindle half pipes through the safe door.
2.
3. Attach an adapter on both cable ends.
Make sure the open adapter side faces the spindle half pipes.
4. Push the lower spindle half pipes (deburred ex works!) all the way into the
adapters.
5. Push the premounted spindle half pipes all the way into each other.
You have successfully assembled the spindle A.
