Bit Function
10 Pin2 is switched if limit value num‐
ber of starts counterclockwise (ccw)
is set
9 Pin2 is switched if limit value num‐
ber of starts clockwise (cw) is set
8 Pin2 is switched if limit value num‐
ber of direction of rotation is set
7 Pin2 is switched if limit value oper‐
ating hours (encoder to voltage sup‐
ply [min]) is set
6 Pin2 is switched if limit value
uptime (encoder in movement [s]) is
set
5 Pin2 is switched if limit value num‐
ber of power-up cycles is set
4 Pin2 is switched if limit value volt‐
age is set
3 Pin2 is switched if limit value tem‐
perature is set
2 Pin2 is switched if limit value veloc‐
ity is set
1 (LSO) Pin2 is switched if limit value posi‐
tion is set.
Pin2 as switching input
Bit Function
32 Pin 2 is high/low active
31 Pin 2 is used as output/input
Preset
The encoder receives an external trigger signal, then the position value is set to
the preset value.
Preset
Bit Function
30 Is used to set the position value to
the preset value
Resetting the relative diagnostic data
The encoder receives an external trigger signal, then the relative diagnostic data
is reset to 0.
Resetting the relative diagnostic data
Bit Function
29 Is used to reset the relative diagnos‐
tic data
5

Operation

5.1 Operating and status indicators
The LED displays the status of the encoder and the communication status.
LED
Status display Color
green
Ö
green
O
Orange
Ö
Orange
O
Red
Ö
Red
O
Ö = flashing
O = lights up
8024548/167W/2019-11-26/de, en
Value
1 = activated
1 = activated
1: activated
1 = activated
1 = activated
1 = activated
1 = activated
1 = activated
1 = activated
1 = activated
Value
0 = high active
1 = low active
0 = Output
1 = Input
Value
1 = activated
Value
1 = activated
Description
Normal operation - communication
Normal operation - no communication
Warning - communication
Warning - no communication
Error - communication
Error - no communication
6 Annex
6.1 Conformities
AHS/AHM36 IO-Link Advanced AHS/AHM36 IO-Link Inox | SICK 16
