1.3 Checking the installation of the motor

Check that:
• the motor is level.
• the gate runs correctly,
• the pinion is correctly driven.
• the 2 mm clearance between the rack and pinion
does not vary significantly .

1.4 Locking the motor

Never lock the motor when the gate is moving as this may damage the motorisation
If these conditions are not satisfied, adjust the
height of the rack.
Once all these checks have been completed,
tighten the nuts to fasten the motor
permanently.
Push the motor handle towards the gate.
The motor is locked.
