Space requirements

Area of application

This product is intended for the motorisation of a sliding gate:
• with a max. length of 7 m and a max. weight of
500 kg

General view of the installation

A
G
H
Mark Designation
A Area lighting*
B Flashing light
C Antenna*
D Safety edge*
E Photoelectric cells
109 109
218
• in PVC, wood or metal
• for a detached house.
B
Mark
*optional accessories
EN - FREEVIA LINE installation and operating guide - SOMFY
25
180
214
C
E
J
F
Designation
F Closing end stop
G Opening end stop
H Motor
J Rack
D
E
