EN
Forced operation mode
This function makes it possible to manipulate the door at any moment (loss of remote control,
photoelectric cell fault, etc.).
Remove the integrated light cover to access the "+" and "-" buttons.
Door stationary:
press the "-" button to close it
press the "+" button to open it.
Door moving: press the "-" or "+" button to stop the door.

4.3 Power outage

Following a power outage, the motor must recognise its «fully open» position again.
Open the door fully using a memorised remote control. The door will open at a degraded speed.
Allow the door to open to the «fully open» position.

5 MAINTENANCE

5.1 Replacing the bulb in the light unit

[1]. Remove the light cover.
[2]. Unscrew and replace the defective light bulb.
[3]. Refit the light cover.
Use a LED G45 24V 4W - BA15s socket light bulb.
5.2

Checking

The safety mechanisms (cells, pedestrian door contact)
Check correct operation every six months (See section 4.2).
5
LED G45 24V 4W
24 V 21 W max.

5.3 Battery replacement

Keytis
Keygo

6 TECHNICAL SPECIFICATIONS

Basic technical specifications
Mains power supply
Power consumption on standby
Max. power consumption
Traction force – Peak force
Use
Number of channels that can be
memorised
Radio frequency
Integrated light
Operating temperature
Dexxo Optimo RTS
230 V - 50 Hz
4 W
120 W
800 N
Intensive use
32
433,42 MHz
< 10 mW
LED G45 24V 4W - BA15s socket
-20 °C / +60 °C
