Wiring the accessories
3
3.4 Offset antenna (optional)
3.5 Video door phone (optional)
NC COM NO
3.6

Key lock (optional)

20
EN - FREEVIA LINE installation and operating guide - SOMFY
The antenna wire can be replaced with an offset
antenna with a greater range.
This is placed on top of the pillar and must be
clearly accessible.
The offset antenna is connected to terminals 1 and
2 of the electronics unit (blue "ANT" label):
• the wire core to terminal 1
• the ground strap to terminal 2
This accessory is not compatible with solar
power.
Only connect one non-powered dry contact .
This accessory is not compatible with solar
power.
