EN

2 PRODUCT DESCRIPTION

2.1 Product components - Fig. 1

Key Number Description
1 1 Motor head
2 1 Motor cover
3 1 Upper cover
4 1 Lintel bracket
5 1 Door bracket
6 2 Ceiling bracket
7 2 Motor head bracket
8 1 Manual release cord
9 1 Link arm
10 1 Travel stop
11 4 Chain retainer pad
12 1 Power cable
13 4 Hex. head M8x16 bolt
14 4 Hex. head M8x12 bolt & washer
15 6 HU8 nut
16 2 Sha
17 2 Circlips
19 4 Self-shaping Ø 4x8 screw
20 2 Special screw for plastic Ø 3.5x12
21a 1 Single part rail
21b 1 Two part rail
21b1 1 Sleeve
21b2 4 Self-shaping Ø 4x8 screw
22 2 HM8 self-locking nut
23a+ 24a 2 +1 Bracket + Spacer
23b 1 Bracket
25 2 Remote control*
* The model and number of remote controls may vary depending on the pack.

2.2 Scope of application - Fig. 2

This motorisation is exclusively intended for the equipement of a garage door for residential
use.
Types of doors (Fig.2)
The DEXXO motorisation is designed to motorise:
A: Projecting up and over door.
B: Sectional door:
- if the door's upper profile is a specific one, use the "sectional door mounting bracket"
ref.: 9009390.
- if the door surface exceeds 10 sq. metres, use the "sectional door adapter" ref.:
2400873.
C: Sideways opening sliding door:
- for side wall mounting, use:
-
a belt transmission rail
-
an "adjustable cranked arm" ref.: 9014481.
- for ceiling mounting, use:
-
an "articulated arm" ref.: 9014482.
D: Swinging door. Use the swinging door kit, ref.: 2400459.
E : Semi and non projecting door. Use:
- a high performance transmission rail
- "the semi and non projecting door kit" ref.: 2400458.
Some doors of this type may prove impossible to automate. Contact SOMFY's technical
department.
Door dimensions (Fig. 3)
For maximum door heights, the motor travel can be optimised:
- By installing the motor head at a 90° angle (Fig. 7-
- By fixing the lintel bracket to the ceiling, behind the lintel itself by up to 200 mm (Fig.
5 - )
- By cutting the link arm to size.
5
).

3 INSTALLATION

If the garage door is the sole means of access to the garage, install an external back release
device (ref. 9012961 or ref. 9012962).
The position in which the drive will be fitted must allow for safe and easy manual release of
the product.

3.1 Installation height - Fig. 4

Measure the distance "D" between the door's highest point and the ceiling.
- If "D" is between 35 and 200 mm, mount the complete system straight onto the ceiling.
- If "D" exceeds 200 mm, mount the complete assembly so that the height "H" falls between
10 and 200 mm.

3.2 Detailed description of installation steps -

Fig. 5 to 15
Mounting the lintel bracket and the door bracket (Fig. 5)
When installing the system directly onto the ceiling (flush with the ceiling), the lintel bracket
can be mounted on the ceiling, if necessary recessed from the lintel by up to 200 mm max
(Fig. 5- ).
Assembling the two part rail (Fig. 6)
[1]. [2]. [3]. Unfold the two parts of the rail
Ensure that the chain or belt is not twisted.
[4]. Assemble the two parts of the rail using the sleeve.
[5]. Mount the complete assembly using the eight mounting screws.
[6]. Tighten the nut to tension the chain or belt. The compressed rubber must measure 18
and 20 mm.
The mounting screws must not penetrate the rail (do not drill).
When installing the system directly onto the ceiling, do not use the sleeve mounting screws.
Fitting the rail onto the motor head (Fig. 7)
Fitting the complete assembly onto the garage ceiling (Fig. 8
to 10)
Fitting to the lintel bracket (Fig. 8)

Ceiling mounting

Flush with the ceiling: mount the system directly onto the ceiling using the rail (Fig. 9).
It is possible to add mounting points at the motor head level (Fig. 9-
Hung from the ceiling: two options:
- mount the system at the motor head (Fig. 10-
- mount the system at the rail (Fig. 10-
To add an adjustable intermediate mounting along the rail, or a mounting at a dimension h
between 250 mm and 550 mm, use the ceiling mounting kit ref.: 9014462 (Fig. 10-
Fitting the arm onto the door and the trolley (Fig. 11)
In case the handle release system is positionned greater height than 1,80 m, it
will be necessary to lenghten the cord to make it accessible to all end-users.
[1]. Release the trolley using the manual release cord.
[2]. Bring the trolley up to the door.
[3]. Attach the arm to the door bracket and the trolley.
Adjusting and fastening the opening travel stop (Fig. 12)
[1]. Release the trolley from
release mechanism and
At this step, make sure that the cord from the manual release system could not
be caught a erwards in a prominent part of the vehicule (i.e. roofbars).
Do not open the door fully, but position it so that it does not reach its own travel stop.
[2]. Slot the travel stop (10) into the rail then turn it by 90°.
[3]. Position the travel stop against the trolley.
[4]. Moderately tighten down the mounting screw.
Do not tighten the mounting screw all the way down. Excessive tightening can
damage the screw and cause the travel stop not to remain in place.
).
a
)
b
)
the runner using the
bring the door to the open
