1.5 Wiring the motor

For your safety, these operations must be carried out with the power supply switched off.
The motor is wired as standard for installation to the le of the gate
To install the motor to the right of the gate, switch the wires connected to terminals 10 and 11 of the
control electronics (green M1 label).
Motor on le -hand side
Connect nothing to terminal M2.
12
EN - FREEVIA LINE installation and operating guide - SOMFY
Brown
Blue
View from inside
Blue
Brown
Motor on right-hand side
View from inside
