3.1.d - Assembling the brush (Fig. 5)
- Position the brush (1) on the ground.
- Lift the front of the machine up by lever-
ing the handle (2) and remove the poly-
styrene support (3).
- Position the flange (4) above the brush
(1).
- Set the button (5) to "I", then press the le-
vers (6), starting up rotation of the brush
until hearing the "CLICK" showing that
the brush has engaged, then release the
levers (6) and set the button (5) to "0".
6
Fig. 5
EN-9
2
5
EN
4
3
4
1
6
