11.1.b - Cleaning the recovery water
tank (Fig. 15)
WARNING:
At the end of the washing operations, it
is compulsory to clean the recovery wa-
ter tank to prevent deposits or scaling
and the proliferation of bacteria, odours
or mould.
- Drain the recovery water as shown in the
relative paragraph, positioning the ma-
chine over a drain outlet.
- Remove the cover (1) and clean the in-
side of the cover and the aspirator safety
float (2) with running water.
- Leaving the hose (3) lowered and the cap
off, add water through the upper opening
(4), cleaning the inside of the tank until
clean water comes out of the drain hose.
- Replace all the components in reverse
order.
EN-20
1
2
4
3
Fig. 15
