Testing The Device - Fronius Testbox - Welding Torch Bedienungsanleitung

Testing the de-
LocalNet devices
vice
RXD
TXD
+24V-LocalNet
Rec. Messages
Trc. Messages
b a d
<<<
LocalNet devices
The display segments simulated by the Welding Torch test box must be activated on the
relevant welding torch. If they are not, the torch is faulty. In this case, inform After-Sales
Service.
If nothing appears on the Welding Torch test box display when the torch buttons are
pressed, then the torch is faulty. In this case, inform After-Sales Service.
Device information
Good (13.9 mA)
Good (16.3 mA)
28.82 V
11987
11991
M s e a s g s e 0
>>>
iJob
Mode
LED
State
Blue
Temp.
Trig 1 Trig 2
< < < > > > P P U
NOTE! The displays will differ
slightly depending on the welding
torch used. The functionality of the
test box remains the same irre-
spective of the welding torch con-
nected.
Press the '>>>' function key
1
- an overview of the displays and
buttons on the relevant device is
displayed
Down
Test welding torch buttons by pressing
2
function
Use the adjusting dial to select the
3
run
mode for the display segment test
1
- the selected mode is applied
25.9C °C
Only when 'manual' mode is selected:
Press the 'Down' function key to go to
4
segment selection
Turn the adjusting dial to test the dis-
5
play segments in sequence
D o w n
Press the 'Down' function key again to
6
return to mode selection
