TIG torches
TIG torches
Identification 2.50 V
Main Up
0.00 V
0.00 V
I - E Down
0.00 V 0.00 V
CWF potentiometer 2.10 V
Supply 4.98 V, 0.004 A
The relevant signal must rise or fall steeply and then run in a straight line from left to right.
If there are any glitches or pronounced unevenness in the signal, this means the torch is
faulty. In this case, inform After-Sales Service.
Press the welding torch buttons and
1
turn the cold-wire potentiometer
- the relevant parameters will appe-
ar
- if the buttons are fully functional,
an acoustic signal will sound
Press the MENU key to return to the
2
main menu
