Testing Welding Torches And Hosepacks In The Tpsi Series; General; Preparations - Fronius Testbox - Welding Torch Bedienungsanleitung

Testing welding torches and hosepacks in the TPSi
series

General

This section describes testing of the following welding torches and hosepacks:
-
-
-
-
The following components can be tested:
-
-

Preparations

MIG/MAG torches
LocalNet devices
Special devices
Info about testbox
4
5
LocalNet devices
50
All variants of the MTGi welding torch (excluding standard welding torches; for the
testing of standard welding torches, see the section on "Standard MIG/MAG welding
torches - TS/TPS, TSt, TPSi series")
All variants of the MTWi welding torch (excluding standard welding torches; for the
testing of standard welding torches, see the section on "Standard MIG/MAG welding
torches - TS/TPS, TSt, TPSi series")
All variants of gas-cooled MHPi hosepacks
All variants of water-cooled MHPi hosepacks
Welding torch and hosepack buttons
Welding torch and hosepack display segments
Main menu
TIG torches
Select
Plug the Fronius System Connector (FSC) on the welding torch into the torch connec-
tion on the FSC adapter
Connect the FSC adapter LocalNet plug to the LocalNet connection socket on the test
box
Device information
RXD Good
TXD Good
+24V-LocalNet
Rec. Messages
Trc. Messages
b a d M s e a s g s e
<<< >>>
1
2
3
-
(13.9 mA)
(16.3 mA)
28.82 V
11987
11991
0
Down
Use the adjusting dial to select the
LocalNet device work area
Press the 'Select' function key
- the 'Device information' screen is
displayed
- the LED above the LocalNet
connection lights up
Turn the welding torch selector switch
on the FSC adapter to the UP/DOWN
position
Device information will appear
