Testing welding torches using the LocalNet plug -
TS/TPS, TSt and MW/TT series

General

This section describes testing of the following welding torches:
-
-
-
-
The following welding torch components can be tested:
-
-
-
Preparations - TS/
TPS and MW/TT
series
MIG/MAG torches
LocalNet devices
Special devices
Info about testbox
LocalNet devices
46
MIG/MAG welding torches in the TS/TPS series that have a LocalNet plug
TIG JobMaster welding torch
All variants of the MTG welding torch
All variants of the MTW welding torch
Welding torch buttons
Display segments on the welding torch
Push-pull motor
Main menu
TIG torches
Select
Device information
RXD Good
TXD Good
+24V-LocalNet
Rec. Messages
Trc. Messages
b a d M s e a s g s e
<<< >>>
1
2
3
-
(13.9 mA)
(16.3 mA)
28.82 V
11987
11991
0
Down
Use the adjusting dial to select the
LocalNet device work area
Press the 'Select' function key
- the 'Device information' screen is
displayed
- the LED above the LocalNet
connection lights up
Connect the device to the LocalNet
connection socket on the test box
Device information will appear
