Testing standard MIG/MAG welding torches - TS/
TPS, TSt, TPSi series

General

This section describes the testing of the following components:
-
-
-
-
Preparations - TS/
TPS series
MIG/MAG torches
TIG torches
LocalNet devices
Special devices
Info about testbox
Preparations - TSt
series
MIG/MAG torches
TIG torches
LocalNet devices
Special devices
Info about testbox
4
5
Torch button on standard MIG/MAG welding torches, all series
Push-pull motor on standard MIG/MAG welding torches in the TS/TPS series that
have a 9-pin control plug (not LocalNet)
PPU potentiometer on standard MIG/MAG welding torches in the TS/TPS series that
have a 9-pin control plug (not LocalNet)
Welding torch buttons on Up/Down torches in the TS/TPS series that have a 9-pin con-
trol plug (not LocalNet)
Main menu
Select
Main menu
Select
Plug the Fronius System Connector (FSC) on the welding torch into the torch connec-
tion on the FSC adapter
Connect the FSC adapter control plug to the MIG/MAG connection on the test box
Use the adjusting dial to select the
1
MIG/MAG welding torch work area
Press the 'Select' function key
2
- the 'MIG/MAG welding torch'
screen appears:
- the LED above the MIG/MAG
connection lights up
Use the control plug to connect the
3
MIG/MAG welding torch to the MIG/
MAG connection on the test box
Use the adjusting dial to select the
1
MIG/MAG welding torch work area
Press the 'Select' function key
2
- the 'MIG/MAG welding torch'
screen appears:
- the LED above the MIG/MAG
connection lights up
Turn the welding torch selector switch
3
on the FSC adapter to the standard po-
sition
