LocalNet devices
PPU-Test
Press „Start motor" for switching
on the PPU-motor.
PPU voltage 9.29V
PPU current 0.00A
Start
motor
The signal must run in a straight line from left to right. If the PPU voltage drops periodically
to 0 V, or there are glitches in the signal, this means the torch is faulty. In this case, inform
After-Sales Service.
In the screen to test the display seg-
1
ments and buttons (e.g. 'MIG/MAG
JobMaster' screen) press the 'PPU'
function key
-
Press the 'Start motor' function key to
2
start the push-pull motor test
-
Press the 'Start motor' function key
3
again to stop the push-pull motor test
Press the 'Cancel' function key
4
Cancel
-
-
the 'PPU test' screen is displayed
parameters are displayed
to stop the push-pull motor test
and
to exit the 'PPU test' screen
