FSC adapter

Control elements
and connections
on the FSC adapt-
er
FSC adapter front view
FSC adapter front view
38
(1) (2) (3)
(5)
(6)
No. Function
(1) Shielding gas connection
(2) Welding torch selector switch
(3) Compressed air connection
(4) LocalNet plug
(5) Control plug
(4)
No. Function
(6) Welding torch connection
