2. Group II + III (starting from 15-36 kg)

2.1 Disassembly of the fi ve-point belt system (G) of the
seat
Loosen the shoulder belts by pressing the belt adjuster
(GV) and pull the harness belts (G2) towards you.
Do not tear at the shoulder pads.
Release the belt ends of the harness belt (G2) on the
reverse side
of the seat part (ST) from the belt anchor (R).
Afterwards you can release the harness belts (G2) and the
shoulder pad belts (SG) from the adjustment unit and pull
out both belt ends through
the shoulder belt lead-through
(G1).
31
In order to remove the
crotch strap, push the belt,
together with the metal plate,
out of the seat part from bot-
tom to top
Press
Now you can completely remove
the fi ve-point belt system.The
central adjustment belt (G5) can
be stored under the adjuster
cover (F).
2.2 Installation / adjustment with ISOFIX (WITHOUT top
tether) and three-point belt of the car (semi-universal)
In group II and III the ISOFIX mechanism is only appro-
ved as additional fi xation. You can attach the seat with
ISOFIX (I), in order to avoid that the seat slips.
Please follow the items in paragraph 1.3.
Attention: Please read up on the authorized seats in the
manual of your vehicle.
Place your child into the HEYNER® MultiRelax AERO Fix
child car seat.
Now guide the shoulder belt of the vehicle through the
guide slit in the belt strap. To ensure an optimum belt
run, the shoulder belt should run along the middle of the
shoulder.
