Protective gloves must be worn at all times during maintenance and cleaning work.
Maintenance and cleaning work must only be carried out if the engine has been turned off and the spark plug
connector has been removed.
• Never remove the spark plug connector when the motor is running! Risk: Electric shock.
• If the tank has to be emptied, this should be done in the open, and with a cold engine. Take care to ensure that no fuel
is spilt.
For warranty and safety reasons, original replacement parts must be used at all times.
6

DESCRIPTION OF COMPONENTS

1 Safety control bracket for the engine brake
2 Front wheel locking device lever (JS63 VARIO C)
3 Drive switch bar
4 Tank cap
5 Air filter
6 Front wheels (JS63 VARIO C)
7 Cutting height adjusting levers
8 Spark plug
9 Handle height adjustment
10 Oil filling nozzle with dipstick
11 Starter cable grip
12 Variable speed switch lever
7

PREPARATION

The following parts are included in the packaging for assembly of the mower:
• Mower with preassembled handle
GB
• Side discharge chute
• Tool bag with the following contents:
– Operator's manual with Declaration of Conformity
– Warranty conditions and Warranty card
– Various fixing parts.
In the unlikely event of a missing part, please contact your dealer.

Opening out the handle (Illustration A1 + E1 + B1 )

IMPORTANT
Avoid damage! Prevent damage to mower control cables when assembling handle system. Do not kink or damage
control cables. Control cables must be inside of handle and unrestricted before tightening hardware.
– Carefully remove mower from packaging.
– Loosen knurled nut (A) approximately 25 mm (1 in.) on each side of upper handle A1 .
– Remove knurled nut (B) and carriage bolt (D) from each side A1 .
– Pull the folded-up Z-shaped handle apart and upwards.
– When upper and lower handles are aligned tighten the knurled nuts (A) on both sides by hand E1 .
– Carefully pull the handle assembly rearward and align the lower handle hole with the desired height setting hole in
bracket (C) B1 .
In this way, three different handle heights can be set.
– From inside pull the bolts (D) on both sides through the bracket and lower handle and screw tight with the knurled nut
(B). Use the same opening in the bracket on both sides (C) B1 .
– Fasten the Bowden cables to the lower part of the handle with the aid of cable ties from the tool bag.
CAUTION
When you activate the bar height adjustment, when loosening the grip nuts (B) B1 and the fixing screws (D)
between the bottom of the bar and the bracket it is possible that unintentional upsetting of the bar may occur. In
addition, this may result in crushed points between the bar bottom and the bracket. This may result in a risk of
injury!
