Starting With A Coin Device; Ending The Massage - Wellsystem Relax_Plus Gebrauchsanweisung

03/2011 1009864-00
NOTE:
Any massage time setting can be entered prior to starting
when using a chipcard (up to the maximum default time
permitted). The massaging pressure can be decreased or
increased at any time whilst the unit is working.
The type of massage cannot be changed!
– Setting the massage time – see page 26.
– Insert the chipcard.
– Lie down on the unit.
– Press the START / STOP button.
The program stored on the chip card will run automatically.
Chip card inserted incorrectly
If the chip card is inserted incorrectly, the error message Err is shown on the
display.
4.3.2

Starting with a coin device

– Set the massage time on the coin device.
– Lie down on the unit.
– Select the type of massage that you want or insert the chipcard.
– Press the START / STOP button.
4.4

Ending the massage

The massage will be terminated automatically after the set massage time has
expired.
When the set massage time has expired, the nozzles move at high speed to
the head end and then change to a smoothing, final massage. The pressure
is reduced for the final massage. This pressure can only be changed by cus-
tomer service. The nozzles move once completely from the head end to the
feet end as for a full body massage.
The massage does not end until the nozzles stop at the end of the foot
and the display blinks at 0.00.
The final massage is omitted if a chipcard is not being used. At the end of the
massage time, the nozzle carriage moves to the head end and comes to a
stop there.
Operation
Operating instructions – 21
