Mounting instructions

6.1

Mounting instructions for inward-opening window

6.1.1 Drilling template for 2 drives
Drill the fitting holes for the drive holders (2), (3) and bracket IW (4),
use the drilling template (colour blue).
f
2
Range of application:
6.1.2 Mounting
Position the drive holders (2) and (3) using the spacer (6).
Remove the spacer and mount the drive holders.
Mount the bracket IW (4).
Mount the pin and quick-release fastener (7) to the drive.
Casement width a
Drive centre
6
28
4
25
390
Casement width a
0 -  mm
1000 - 00 mm
Drive centre
3
2
Mounting dimension f
1 mm
1/ a
f
6
4
390
3
