02.2008
Installation

Side view

Siemens AG 6SE7087-6JP60
SIMOVERT MASTERDRIVES
The unit is mounted directly to a mounting surface. Fixing is by means
of two or four M5 screws.
Mounting surface
250 mm
220 mm
0.55 kW
Fig. 5-2 Dimension drawings for housings up to 90 mm wide
Mounting surface
250 mm
220 mm
Side view
Fig. 5-3 Dimension drawings for housings 135 mm and 180 mm wide
Operating Instructions
Cutouts
for M5 screws
22.5 mm 33.75 mm
45 mm 67.5 mm
1.1 / 1.5 kW
Front view (without front panel)
Cutouts
for M5 screws
22.5 mm
135 mm
5.5 / 7.5 kW

Front view

Installation
45 mm
90 mm
3.0 / 4.0 kW
180 mm
11 / 15 kW
5-3
