Technical Data
Main
contactor
-X102.20
12-6
Thermal overload of the external braking resistor must be avoided by
appropriate configuration. If necessary, the converter can be switched
off by a thermoswitch which monitors the temperature of the external
braking resistor (see Fig. 12-1).
SIMOVERT MASTERDRIVES
VC Compact PLUS
-X1
HS1
.21 HS2
Y = Binary input which activates the fault trip of the converter,
Parameterization for the possible binary inputs Y:
Terminal Binary input
-101.3 1
.4 2
.5 3
.6 4
.7 5
.8 6
-102.19 7
Fig. 12-1 Converter with external braking resistor and fault trip via
thermoswitch
-X6
G
-X6
H
-X101.1
Y
e.g. -X101.7 (binary input 5)
Parameterization
P586 = 10
P586 = 12
P586 = 14
P586 = 16
P586 = 18
P586 = 20
P586 = 22
Operating Instructions
02.2008
ext.
braking
resistor
Thermo-
ϑ
switch
