Converter
Type Rated
power output
current
I n
[kW] [A]
0.55 1.5 6SE7011-5EP60
1.1 3.0 6SE7013-0EP60
1.5 5.0 6SE7015-0EP60
3 8.0 6SE7018-0EP60
4 10.0 6SE7021-0EP60
5.5 14.0 6SE7021-4EP60
7.5 20.5 6SE7022-1EP60
11 27.0 6SE7022-7EP60
15 34.0 6SE7023-4EP60
Siemens AG 6SE7087-6JP60
SIMOVERT MASTERDRIVES
Braking power of the integrated brake chopper:
Order No. Smallest perm.
resistance value
for ext. braking
resistor R min
[Ω]
80
80
80
40
40
20
20
11
11
Regenerative operation is possible with converters if an external
braking resistor is connected. The regenerative energy is converted to
heat in the braking resistor. The braking resistor should be mounted
outside the control cubicle in order to avoid the electronic components
in the cubicle becoming overheated.
To protect the brake chopper against an overload of current, the
smallest permissible resistance value of the braking resistor must not
be fallen short of. The control electronic system monitors the pulse duty
factor of the brake chopper and switches it off in the event of an
overload.
Length of the connecting cable between the converter and the external
braking resistor < 15 m.
P = Continuous power
DB
P = 4 P
20 DB
P = 6 P
3 DB
P 1.50
3
P 1
20
P 0.25
DB
3 20 23
Operating Instructions
Max. Rated
brake braking
chopper power P20
current at R min
[A] [kW]
10
10
10
20 10
20 10
40 20
40 20
70 36
70 36
= Power permissible for 20 s every 90 s
= Power permissible for 3 s every 90 s
90 t/s
Technical Data
Short-time Continuous
braking
power P3 at power PDB
R min
[kW]
5 7.5
5 7.5
5 7.5
15
15
30
30
54
54
braking
at R min
[kW]
1.25
1.25
1.25
2.5
2.5
5
5
9
9
