Connecting-up
Mains connection X1
Brake resistor, X6
Capacitor module
External DC24 V supply X9
X533 Safe STOP (option)
DC24 V output,
RS485 (USS) X100
Bus terminating resistor (USS) S1
Terminal strip X101
RS232 / RS485 (USS) X103
Motor connection X2
Shield connection
for control cables
7-2
SIEMENS
PMU
X100
A
S1
X101 B
X103 C
Fig. 7-1 Connection overview for units up to 90 mm wide
PE3
X3 DC link bus
−
module
+
Slot A
Slot B
Terminal strip
X102
Encoder connection
X104
Shield connection
for motor cable
6SE7087-6JP60
