12x
6
6. Screw the base plate
with screws.

Attaching the exhaust hood

NOTICE
Risk of damage to property!
When lifting and carrying the ex-
haust hood, always carry it by the
housing and never by the glass cover!
This could otherwise break.
6
into the ceiling
Assembly
1. If there is a blue protective film on the top
part of the exhaust hood 1, remove it.
7
8
9
2
1
2. Place the glass cover
hood
1
and attach using the screws 7, con-
ical washers
8
and the rubber fittings 9.
5
10
3. Screw four mounting rails
haust hood
1
using four screws
each case.
4. First attach the four other mounting rails
to the already attached mounting rails
using four screws 10, four washers
and four nuts
11
each, so that the ex-
haust hood hangs at the correct height
later on (they must protrude at least one
hole width over the lower mounting rails
so that they can be firmly attached to the
base plate
6
later).
Page EN-15
2
on the exhaust
11
12
10
5
to the ex-
10
in
5
12
