Page EN-16 Assembly
4
14
1
5. For exhaust air operation: Carefully in-
sert both plastic check valves into the air
outlet opening at the top of the appliance
(gently bend the flaps a little so as not to
break off the sensitive plastic tabs).
Attach the exhaust air hose
with a diameter of 153 mm (see marking
on the hose) to the exhaust hood
secure it with a cable tie 14.
16
3
5
1
6. Place the two-piece flue screen
the mounting rails 5 above the exhaust
hood 1. The end with the ventilation slots
16 must be facing upwards.
6
4
5
1
7. Lift the exhaust hood
onto the housing, hold it to the base plate
6
4 opening
5
10,
1 and
4
14
8. For exhaust air operation: Attach the ex-
haust air hose
of 150 mm (see marking on the hose) to
the vent opening in the ceiling and secure
it with a cable tie 14.
9. Connect the power supply.
13
3 over
10. Pull the top of the flue screen
1 with two persons
at the top, and screw the mounting rails
to the base plate 6 using four screws
four washers 12 and four nuts
4 opening with a diameter
4x
way up to the ceiling and screw it to the
base plate 6 using four screws 13.
8x
11 12 10
11.
6
3
3 all the
