Expansion modules
Output current dependencies
Current at 12 V output 17/18
or 19/20 in mA
20
40
60
80
100
Mechanical
Dimension in cm (H x W x D)
Weight in g
Housing material
Color
Environmental
Minimum operating
temperature in °C
Maximum operating
temperature in °C
Minimum storage temperature
in °C
Maximum storage temperature
in °C
Maximum relative humidity in
%
Protection class
Bosch Sicherheitssysteme GmbH
Technical data | en
Current at AUX 28 V 1/2 or
4/5 in mA
18
41
57
72
88
20 x 14 x 1.4
400
ABS + PC-FR
Signal white (RAL 9003)
0
55
-25
75
93
IP30
2018.02 | 05 | F.01U.076.548
