Expansion modules
Maximum current
consumption in mA (other
functions at 12 V)
Maximum current
consumption in mA (other
functions at 28 V)
Minimum current consumption
in mA (other functions at 28 V)
Connection options
Primary lines PL 1 - PL 6
Connection options
Terminal resistance in kΩ
Interruption voltage in V
Maxiumum line resistance in Ω 100
Alarm threshold
Maximum response time in ms 200
Control outputs S1 - S3
Principle
Maximum voltage in V
Maximum over threshold
voltage in V
Maximum current in mA
Bosch Sicherheitssysteme GmbH
Technical data | en
370
180
20
6 detector zones can be
programmed as holdup,
intrusion, tamper or bolt
– 12k1 for ISP-EMIL-120
and ISP-PCBA-EMIL
– 4k7 for ISP-EMIL-3RDP
6
± 40% of terminal resistance
Open collector, active 12 V, 0
V switching
30
1.4
20
