flexotron800
Signalbezeichnung
HeatingSettings.Cor_Do1(0)
HeatingSettings.Cor_Do1(0)
HeatingSettings.Cor_Do2
HeatingSettings.Cor_Do3
HeatingSettings.Cor_Do4
HeatingSettings.Cor_Do5
P100013568
Modbus-
Typ
BACnet
Adresse
X,4
81
X,4
81
X,4
82
X,4
83
X,4
84
X,4
85
Default-
Beschreibung
Wert
Connected signal on DO1:
0 = Not used
1 = HS1-PumpA
2 = HS1-PumpB
3 = HS2-PumpA
4 = HS2-PumpB
5 = HS3-PumpA
6 = HS3-PumpB
7 = Start pump A CS1
8 = Start pump B CS1
9 = HW1-Pump
10 = HP1-Pump
11 = Frequencer
12 = Start1 Boiler (Not used 3.2)
13 = Start2 Boiler (Not used 3.2)
14 = Sum alarm
15 = A-sum alarm
16 = B + C-sum alarm
17 = Timer1
18 = Timer2
19 = Timer3
20 = Timer4
21 = Timer5
22 = Inc HS1-Act.
23 = Dec HS1-Act.
24 = Inc HS2-Act.
25 = Dec HS2-Act.
26 = Inc HS3-Act.
27 = Dec HS3-Act.
28 = Inc CS1-Act.
29 = Dec CS1-Act.
30 = Inc HW1-Act.
31 = Dec HW1-Act.
32 = Inc HW2-Act.
33 = Dec HW2-Act.
34 = Bypass CS1-CV1
35 = Start Cooling Unit
36 = HB1 Start Low
37 = HB1 Start High
38 = HB2 Start Low
39 = HB2 Start High
40 = HB3 Start Low
41 = HB3 Start High
42 = HB4 Start Low
43 = HB4 Start High
44 = HB1 Pump Start
45 = HB2 Pump Start
46 = HB3 Pump Start
47 = HB4 Pump Start
48 = Transport Pump Start
49 = Extra Circuit Pump Start
Connected signal on DO2:
(See signal list for DO1)
Connected signal on DO3:
(See signal list for DO1)
Connected signal on DO4:
(See signal list for DO1)
Connected signal on DO5:
(See signal list for DO1)
Input/Output
47/92
